Socket

AF series

Mr.Socket

PDF fileRoHS
800x514 af800x514 af 2 800x514 af%e3%81%ae%e3%82%b3%e3%83%94%e3%83%bc
  • Possible to mount components without soldering.
  • After mounting, through-hole changes to socket.
  • Possible to mount by automatic mounting machine.

■Part number

Part number Adaptive male pin diameter Package
AF-0.5(L) 0.45～0.6φ Reel (1000pcs/reel)
AF-0.5(H) 0.40～0.6φ Reel (1000pcs/reel)
AF-0.7(L) 0.60～0.8φ Reel (1000pcs/reel)
AF-0.7(H) 0.60～0.8φ Reel (1000pcs/reel)
AF-0.9(L) 0.80～1.0φ Reel (450pcs/reel)
AF-0.9(H) 0.80～1.0φ Reel (450pcs/reel)

Example of Bulk package part number : AF-0.5(L)-B　（Please put "B". 100pcs/pack.)

For details, please refer to the PDF file.
